ABB 1MRK002122-ABR02 Relion 615 Binary I/O Module

The ABB 1MRK002122-ABR02 Relion 615 Binary I/O Module is a plug-in binary I/O module of the ABB Relion 615 series protection and control IEDs, providing binary input/output interfacing for relay configurations that require additional digital I/O beyond the base unit. It belongs to the 1MRK002122-xxx plug-in module family — the same family that includes the -ABR01 binary I/O module and the -ABr03 optical short-range line data communication module.

Key Features

1. Plug-in binary I/O module for ABB Relion 615 series protection and control IEDs
2. Extends the IED's binary input/output capability for distribution protection applications
3. Family member of 1MRK002122-xxx plug-in modules (incl. -ABR01 binary I/O, -ABr03 optical communication)
4. 24 V DC I/O class
5. Compact plug-in module, DIN-rail mounting
6. Made in Switzerland

1. Part Number: 1MRK002122-ABR02
2. Product Type: Binary I/O module (plug-in, for Relion IEDs)
3. System: ABB Relion 615 series protection & control IEDs
4. Function: Binary input/output interfacing for the IED
5. Voltage Class: 24 V DC
6. Rated Current: 1 A
7. Dimensions: 90 × 180 × 70 mm
8. Weight: 0.172 kg
9. Mounting: DIN rail (35 mm)
10. Origin: Switzerland

1. Verify the exact variant (-ABR01/-ABR02/-ABr03…) and its function against the Relion 615 ordering documentation — sibling codes differ in function.
2. De-energize the IED and disconnect auxiliary supply before inserting or removing the module; follow ESD precautions.
3. Insert the module into the designated slot of the IED; seat and latch it fully.
4. Wire the binary inputs/outputs per the IED connection diagram, observing polarity and voltage class (24 V DC).
5. After power-up, verify I/O status and configuration via the IED front panel / PCM600 before returning the protection to service.

1. What is the 1MRK002122-ABR02? It is a plug-in binary I/O module for ABB Relion 615 series protection IEDs, extending the relay's digital I/O capability .
2. How does it relate to other 1MRK002122-xxx codes? The family includes the -ABR01 (binary I/O module), -ABR02 (I/O module) and -ABr03 (optical communication module).
3. What power/voltage class does it use? 24 V DC class, 1 A rated (sibling -ABR01 data).
4. Where is it made? Switzerland.
