HONEYWELL 51304518-150 TDC3000 APM Control Module

🔴The Honeywell 51304518-150 is a High-Level Analog Input / HART input module for the Experion Series-C I/O system (Experion PKS / PlantCruise). It provides 16 analog input channels accepting 4–20 mA signals from both traditional transmitters and HART devices, with HART data available for status, configuration, and as additional process variables. Designed for fault-tolerant process control, it features per-channel isolation, independent current-limiting protection, and 16-bit resolution — a standard spare part for installed Honeywell Experion plants.

1️⃣Key Specifications

• Manufacturer: Honeywell
• Model / Part Number: 51304518-150
• Product Family: Experion Series-C I/O Module
• Product Type: High-Level Analog Input / HART Input Module (16-point)
• Input Channels: 16 (high-level analog + HART)
• Input Signal: 4–20 mA DC (traditional and HART devices)
• HART Capability: Supports HART multivariable instruments; secondary/tertiary variables usable as control variables
• Resolution: 16 bits
• Accuracy: ±0.075% (23.5 ±2 °C); ±0.15% (0–60 °C)
• Scan Rate: 50 ms
• Isolation: Per-channel isolation (channel-to-channel, channel-to-PM, channel-to-power supply)
• Protection: Independent current-limiting protection per channel (non-incendive)
• Mounting: Series-C I/O chassis / IOTA (redundant IOTA: CC-TAIX01)
• Origin: USA

• 16-Point High-Level AI with HART: Accepts 4–20 mA from conventional and HART transmitters on the same module, maximizing field-device flexibility.
• Multivariable HART Data: HART secondary and tertiary variables can be brought into the control strategy as process variables, not just for diagnostics.
• High Accuracy: 16-bit resolution with ±0.075% accuracy under reference conditions for tight loop control.
• Per-Channel Safety: Independent current-limiting and isolation protect the module and backplane from field faults.
• Experion Integration: Configured and monitored through the Experion engineering environment; standard Series-C form factor with redundant IOTA options.

• Analog process measurement (pressure, temperature, flow, level) in Experion PKS plants
• HART transmitter integration with multivariable process variables
• Refinery, chemical, and power plant process control loops
